Factory of tubular
Radiator
This radiator is made of welded steel pipes (Ч 0146), of material DC01 in standard EN 10305-3, EN 10305-5, of “D” profile with dimensions of 30×40 mm, and the ribs are made of round pipes with a diameter of Ø22 mm. Hot water is used as the heating fluid, while heat is transferred by convection and radiation. The radiator has 4 connections of 1/2″ dimension.
Antracit
Gold
Metalic
Half mat
The installation of the radiator is extremely simple and easy, the installation depth during installation is 65 mm – 110 mm, and the installation instructions, with the warranty card and the installation kit, which consists of 3 or 4 mounting brackets depending on the size of the radiator with the corresponding screws and dowels, vent tap 1/2″, nickel plug 1/2″, are included in the package, as well as protective plastic caps.
| Height H (mm) | Width W (mm) | Connection distance E (mm) | Number of tubes | Weight (kg) | Cubage (L) | Thermal performance 75/65/20℃ ΔT 50 K | Thermal performance 55/45/20 ℃ ΔT 30 K | Connection dimensions G (col) |
| 800 | 400 | 350 | 14 | 3,72 | 3,00 | 277 | 145 | 1/2 |
| 1000 | 400 | 350 | 16 | 4,53 | 3,77 | 342 | 179 | 1/2 |
| 1200 | 400 | 350 | 20 | 5,34 | 4,54 | 404 | 212 | 1/2 |
| 1500 | 400 | 350 | 22 | 6,46 | 5,36 | 495 | 260 | 1/2 |
| 1800 | 400 | 350 | 26 | 7,58 | 6,18 | 583 | 307 | 1/2 |
| 1500 | 400 | 350 | 27 | 7,08 | 5,72 | 527 | 277 | 1/2 |
| 1800 | 400 | 350 | 33 | 8,58 | 6,84 | 654 | 346 | 1/2 |
| 800 | 550 | 450 | 14 | 4,34 | 3,45 | 332 | 174 | 1/2 |
| 1000 | 500 | 450 | 16 | 5,30 | 4,29 | 410 | 215 | 1/2 |
| 1200 | 500 | 450 | 20 | 6,25 | 5,13 | 486 | 255 | 1/2 |
| 1500 | 500 | 450 | 22 | 7,59 | 6,05 | 594 | 314 | 1/2 |
| 1800 | 500 | 450 | 26 | 8,93 | 6,97 | 696 | 369 | 1/2 |
| 1500 | 500 | 450 | 27 | 8,25 | 6,56 | 637 | 336 | 1/2 |
| 1800 | 500 | 450 | 33 | 9,99 | 7,89 | 787 | 415 | 1/2 |
| 800 | 600 | 550 | 14 | 4,96 | 3,89 | 387 | 203 | 1/2 |
| 1000 | 600 | 550 | 16 | 6,06 | 4,80 | 479 | 252 | 1/2 |
| 1200 | 600 | 550 | 20 | 7,17 | 5,71 | 567 | 299 | 1/2 |
| 1500 | 600 | 550 | 22 | 8,72 | 6,74 | 692 | 367 | 1/2 |
| 1800 | 600 | 550 | 26 | 10,27 | 7,77 | 809 | 431 | 1/2 |
| 1500 | 600 | 550 | 27 | 9,41 | 7,40 | 747 | 395 | 1/2 |
| 1800 | 600 | 550 | 33 | 11,41 | 8,93 | 919 | 485 | 1/2 |
| 800 | 700 | 650 | 14 | 5,58 | 4,34 | 442 | 232 | 1/2 |
| 1000 | 700 | 650 | 16 | 6,83 | 5,32 | 547 | 288 | 1/2 |
| 1200 | 700 | 650 | 20 | 8,08 | 6,30 | 648 | 343 | 1/2 |
| 1500 | 700 | 650 | 22 | 9,85 | 7,43 | 791 | 420 | 1/2 |
| 1800 | 700 | 650 | 26 | 11,62 | 8,56 | 922 | 493 | 1/2 |
| 1500 | 700 | 650 | 27 | 10,58 | 8,24 | 858 | 454 | 1/2 |
| 1800 | 700 | 650 | 33 | 12,82 | 9,98 | 1051 | 555 | 1/2 |
