NK STANDARD
A tubular radiator that takes up very little space. Primarily designed for bathrooms but equally at home in living rooms, offices, and kitchens.
6 barWorking pressure
300–2000 WOutput
5 yearsWarranty
Technical specifications
Width W 400 mm · Connection spacing E 330 mm · Connection G ½″
Height H (mm)
750
- No. of tubes
- 14
- Weight (kg)
- 4,70
- Volume (L)
- 3,50
- Output ΔT 60K (W)
- 491
- Output ΔT 50K (W)
- 394
- Output ΔT 30K (W)
- 212
Height H (mm)
1120
- No. of tubes
- 21
- Weight (kg)
- 6,80
- Volume (L)
- 5,30
- Output ΔT 60K (W)
- 744
- Output ΔT 50K (W)
- 594
- Output ΔT 30K (W)
- 317
Height H (mm)
1490
- No. of tubes
- 28
- Weight (kg)
- 9,20
- Volume (L)
- 7,00
- Output ΔT 60K (W)
- 993
- Output ΔT 50K (W)
- 793
- Output ΔT 30K (W)
- 423
Height H (mm)
1860
- No. of tubes
- 35
- Weight (kg)
- 11,10
- Volume (L)
- 8,60
- Output ΔT 60K (W)
- 1234
- Output ΔT 50K (W)
- 983
- Output ΔT 30K (W)
- 520
Interested?
Request a quote
for this radiator
We manufacture to order any dimension, any RAL colour, with or without an electric heater.
